DoorProtect Plus Detector (Fibra)
Save
100%
100%
Wired opening detector that notifies of first signs of room intrusion by means of a broken door or window. It can be mounted on all types of doors including a metal base. The device detects the door or window being opened by means of British-made high-end reed switches on which the magnetic field acts. It can operate in transmitter mode, sending a signal from the 3rd-party wired sensor to the hub. The device protects even windows left open for ventilation. The accelerometer registers changes in vertical slope angle, bangs or vibration and sends an alarm to the hub.
- Bus connection with 4-core cable, up to 2000 meters (when using twisted pair U/UTP CAT5)
- Reed switch and accelerometer sensing element
- Alarm signal delivery time of 0.15 s
- Magnet can be installed on the right or left side of the detector
- Connection for additional detector
| Technical Specifications | |
| Classification | Point magnetic and contact security detector |
| Installation method | Indoors |
| Compatibility | Operates with Hub Hybrid (2G) and Hub Hybrid (4G) only |
| Sensing element | 2x Reed switch, 1x accelerometer |
| Alarm signal delivery time | 0.15s |
| Activation threshold | Small magnet: 1 cm Big magnet: 2 cm |
| Opening sensors actuation | Up to 2,000,000 (for each reed switch) |
| Additional detector connection | Wired detector with the normally closed (NC) contact type |
| Fibra technology | Recommended cable type for detector connection: Signal cable (4 x 0.22 copper) / Twisted pair U/UTP CAT5 (4 x 2 x 0.51) Connection wire length: Up to 2000m Device polling period: 12−300 s |
| Power supply | Power supply voltage: 24V Power consumption: up to 55 μA |
| Permissible humidity | Up to 75% |
| Operating temperature range | -10°С to +40°С |
| Anti-sabotage | Protection against fraud Tamper-resistant |
| Dimensions | 90.5mm х 21mm x 18.5mm |
| Weight | 54g |
| Certification | EN 50131 (Grade 2), PD 6662:2017, IP50 |
