IP Box Camera (2MP, Smart)

Save 100%
Supports VCA IP Box Camera | UNV
Call us for a price
IPC542E-DLC-C

Part of the UNV professional range, this IP box camera boasts an impressive 2 megapixel HD recording resolution and supports up to Ultra 265 compression. This camera also has smart video-analytic features built-in.

- Resolution 2MP (1920 x 1080), POE
- Supports C and CS Lens Mount
- Day/Night, IR Cut Filter, 3D DNR
- True WDR, OSD, Triple Streams
- Privacy Mask, Motion Mask, ROI, 9:16 Corridor Format Support
- Supports H.264, H.265 or Ultra H.265
- ONVIF Compliance (Profile S)
- Temperature Range -20°C to 60°C
- Wide Voltage Range (±10%)
- Metal Housing

Camera

Image Sensor:
Aptina CMOS (1/2.8")
Resolution:
2MP
Effective Pixels (H x V):
1920 x 1080
TV System:
PAL / NTSC
Shutter Speed:
Auto/Manual, 1/1~1/100000s
Signal-to-noise Ratio:
≥52dB
Iris:
DC-Iris/P-Iris, DC 5V (4 Pins)
Back Light Compensation:
Via OSD Menu
Wide Dynamic Range:
120dB
Digital Noise Reduction:
2D/3D
Gain Control:
Auto
Sync Mode:
Internal
White Balance:
Auto/Manual
Lens:
Not included
Field of View:
Depends on lens used
Scanning:
Progressive Scan
Onboard Recording:
Yes, to MicroSD card up to 128GB

Day/Night

Day & Night:
IR Cut Filter (Smart IR)
Minimum Illumination:
Colour 0.0005Lux, B/W 0.0001Lux
IR Range:
N/A

Network

Ethernet:
RJ45 10/100
Supported Protocols:
IPv4,IGMP,ICMP,ARP,TCP,UDP,DHCP, RTP,RTSP,RTCP,DNS,DDNS,NTP,FTP,UPnP,HTTP,HTTPS,SMTP,SSL
ONVIF:
Supports ONVIF (Profile S, Profile G)
POE:
Yes
Main Stream:
1920x1080@30fps
Sub Stream:
720x576@30fps

General

Power:
12V DC (+/- 10%) / 24V AC (+/- 10%)
Housing:
Metal
Power Consumption:
Max 6.8W
Operating Temperature:
-20°C ~ +60°C
Operating Humidity:
10% - 90% RH
Ingress Protection:
N/A
Approvals:
CE / FCC
Weight:
480g

All dimensions are in millimetres (mm)

HOU-METRO

Cable managed CCTV Camera Housing & Bracket

- Die-cast Aluminium Side-opening housing
- Light Ivory powder coating and stove finished
- With heater
- Dual Voltage (12vDC / 24vAC) or Mains 240vAC
- Optional Pole mount available

£65.00 (£78.00 inc VAT)
TPH-1000M
BR-09

Silver aluminium bracket suitable for any type of CCTV body camera.

- 170(L) x 64(W) x 104(H)mm
- Max 5 Kgs

£5.25 (£6.30 inc VAT)
BR-09
BR-07

> Length 285mm
> Max 10Kg

£10.00 (£12.00 inc VAT)
BR-07
BR-10

Black aluminium bracket suitable for any type of CCTV body camera.

- 170(L) x 64(W) x 104(H)mm
- Max 5 Kgs

£5.25 (£6.30 inc VAT)
BR-09

This camera has the following special features:

ANR (Automatic Network Replenishment)
ANR is a feature which allows a camera to record to an onboard MicroSD card, if it loses connection with the NVR. Once the connection has been re-established, the footage is transferred to the NVR. This feature requires ANR support from the camera and NVR.


VCA (Video Content Analysis)

VCA is the ability to automatically analyse video to detect temporal and spatial events. This camera has the capability to do the following:

  • Intrusion Detection - Entering and loitering in a pre-defined virtual region
  • Line Crossing - Detect when a pre-defined virtual line has been crossed
  • Motion Detection - Movement within a pre-defined virtual region
  • Recognition - Face and audio detection
  • Tamper Identification - Detect when the camera has been phyiscally tampered with
  • Statistical Analysis - People counting
