Uniview 300W Redundant PSU

Home/Uniview IP/Uniview IP Recorders (NVR)/32-128 Channel IP NVRs/Uniview 300W Redundant PSU

2 of 9

Save
100%

Call us for a price

Order Code: PWR-300A-IN

Description

Redundant Power Supply for recorders with large quantities of hard disk drives, such as NVR516 and NVR824

- Protection against short circuit, overload & overvoltage
- Front panel indicator lights alert to normal and abnormal conditions
- Meets regulatory standards: UL, TUV, CE

Specifications
AC Input
Voltage	90 ~ 264V AC
Frequency	47 ~ 63Hz
Power Factor	≥ 0.95
Input Current	≤ 4A
Input Protection	Input under-voltage or over-voltage
DC Output
Voltage / Electricity	+12VDC/25A，+12Vsb/1A
Source Regulation	±1%
Load Regulation	±3%
Stabilized Voltage Precision	±5%
Output Power	312W max
Output Protection	Output short circuit, over-current & over-voltage protection
General
Indicator Light	Normal: Green “On”; Abnormal: Green “Off”
Working Temperature	0 ~ 55°C
Storage Temperature	-40°C ~ 70°C
Heat Dissipation	Fan draft design
Dimensions	234.9mm x 40.13mm x 101.6mm
Conformity Standards
EMC	EN55022, EN55024
NEBS	GR-63-CORE ISSUE 2
Safety	IEC60950-1, GB4943-2001
Approvals	UL, TUV, CE
