PAC MT Admin Reader

Call us for a price

*Lead time of 2-3 days*


Administration Kit for adding credentials into PAC Access Central or EasiNet Residential Software.

- Includes USB cable for connecting to the PC and software CD with all relevant drivers
- Low Frequency (125kHz and 153.6kHz) and High Frequency (13.56MHz)
- Audible Sounder and Red/Green LEDs
- If using a Magnetic stripe reader or other 3rd part Wiegand reader, connections are provided on the rear of the reader
- The Admin Reader can also be used for connecting a PAC 512 series controller to the PC
- Security Grade 3
- IP65 rated

Technical Specifications
Programmable Output Formats PAC, PAC32, PAC64 and Wiegand
Supported ID Device formats PAC (Cards and Tokens)
KeyPAC (Cards and Tokens)

PAC OPS™ Lite (Cards and Tokens)
PAC OPS™(Cards and Tokens)
Maximum Read Range Up to 30mm
Intruder Grading Security Grade 3, Environmental Class 2A
Ingress Protection Rating IP65
Audio Visual Indication Audible Sounder and Red/Green LEDs
Tamper Output Yes (dependent on controller specification), meets EN 50131-1 & 3
Recommended Cabling 6 core 24 AWG alarm cable unscreened for PAC
Operating Voltage 5V USB
Maximum Current Requirements <250mA @ 5V DC
Weight 230g
Standards Compliance UKCA, CE, UL, FCC, IC, RoHS & WEEE compliant
Operating temperature range -40°С to +66°С
Permissible humidity 10% to 85%
Dimensions 130mm х 88mm x 31mm
