Architect RFID HF Reader (Mullion)
Save
100%
100%
The Architect One is a mullion RFID reader specially designed for installation in small spaces, for example on door frames or narrow flush box mounting. Its small size and intelligent design make it easy to incorporate into any installation environment with a 3m plug-in/plug-out connector cable for ease of wiring.
- Accelerometer-based Tamper Detection System
- High Frequency (13.56MHz)
- Audible Sounder and RGB LEDs
- IP65 rated
| Technical Specifications | |
| Programmable Output Formats | PAC, PAC64 |
| Supported ID Device formats | PAC OPS™ Lite (Cards and Tokens) PAC OPS™(Cards and Tokens) |
| Maximum Read Range | Up to 60mm for HF |
| Protection Rating | IK10 |
| Ingress Protection Rating | IP65 |
| Audio Visual Indication | Audible Sounder and 2 x RGB LEDs (360 configurable colours) |
| Tamper Output | Accelerometer-based tamper detection system with key deletion option |
| Recommended Cabling | 6 core 24 AWG alarm cable unscreened for PAC |
| Operating Voltage | 9V to 15V DC |
| Maximum Current Requirements | <130mA @ 12V DC |
| Weight | 200g |
| Standards Compliance | CE, UL, FCC, IL |
| Operating temperature range | -30°С to +70°С |
| Permissible humidity | 0% to 95% |
| Dimensions | 112mm х 42mm x 22mm |
