Architect Bluetooth RFID HF Reader (Mullion)
Save
100%
100%
The Architect One Blue is a mullion RFID/Bluetooth/NFC reader specially designed for installation in small spaces, for example on door frames or narrow flush box mounting. It is specially designed for all your high security access control applications coupled with industry leading Mobile ID support for user friendly deployments. Its small size and intelligent design make it easy to incorporate into any installation environment
- Accelerometer-based Tamper Detection System
- High Frequency (13.56MHz), Bluetooth and NFC
- Audible Sounder and RGB LEDs
- IP65 rated
| Technical Specifications | |
| Programmable Output Formats | PAC, PAC64 |
| Supported ID Device formats | PAC OPS™ Lite (Cards and Tokens) PAC OPS™(Cards and Tokens) |
| Maximum Read Range | Up to 45mm for HF Up to 20m for Mobile IDs (configurable) |
| Protection Rating | IK10 |
| Ingress Protection Rating | IP65 |
| Audio Visual Indication | Audible Sounder and 2 x RGB LEDs (360 configurable colours) |
| Tamper Output | Accelerometer-based tamper detection system with key deletion option |
| Recommended Cabling | 6 core 24 AWG alarm cable unscreened for PAC |
| Operating Voltage | 9V to 15V DC |
| Maximum Current Requirements | <150mA @ 12V DC |
| Weight | 200g |
| Standards Compliance | CE, UL, FCC, IL |
| Operating temperature range | -30°С to +70°С |
| Permissible humidity | 0% to 95% |
| Dimensions | 112mm х 42mm x 22mm |
