SFX Internal CAT5 (Solid Copper, LSZH, Purple, 305m)

£78.00
(£93.60 inc VAT)
+

SFX-CBL-INT-CAT5-PUR

This internal cable is specifically designed for CCTV use over long distances

- Cat5 UTP
- 4 pairs, solid cable
- Verified performance to ISO/IEC 11801 and ANSI/TIA-568-C.2
- 305m / 1000ft
- 24 AWG solid copper conductors
- Colour: Purple



Technical Specifications
Cable Construction
Conductor Bare Copper
Conductor Diameter (mm) 0.47 ±0.01
AWG 24
Insulation
Insulation Thickness (mm) 0.18
Insulation Diameter (mm) 0.88 ±0.08
Insulation Colours Blue+White/Blue; Orange+White/Orange; Green+White/Green; Brown+White/Brown
Jacket
Material LSZH
Jacket Thickness (mm) 0.49 ±0.03
Overall Diameter (mm) 4.80 ±0.03
Jacket Colour Purple RAL 4005
Sheath Printing Cat 5e UTP 4 PR 24AWG LSZH ISO/IEC 11801 ANSI/TIA 568C.2 (PO) (m)
Reaction to Fire Eca
Electrical Characteristics
Max Conductor DC resistance @ 20°C <115Ω/km
Rated Temperature -40°C to +70°C
Impedance (1-100MHz) 100Ω ±15Ω
Test Standards ISO/IEC 11801; ANSI/TIA 568-C.2
