WiFi Access Point (Dual Band, 2.4GHz/5GHz, Outdoor)
The ‘Patriot-DB’ is a long-range outdoor dual-band 802.11n/ac Access Point. It comes with dual 7dbi omnidirectional antennas, as well as a mounting bracket to fix the access point to a wall. The end cap contains a waterproof gasket. Power and data are supplied over the Ethernet connection using proprietary Power over Ethernet (POE); POE adapter and power supply included.
- Long Range Outdoor AP/CPE
- IEEE 802.11a/b/g/n/ac
- WiFi speeds up to 150Mbps (2.4GHz) and 433Mbps (5GHz)
- Operation modes: AP Bridge/Repeater/Client Router/Client Bridge
- Dual 7Dbi omnidirectional antennas
- Robust weatherproof case, IP65 rated
- Mounting bracket included
- Built-in lightning protection (15kV ESD)
| Technical Specifications | |
| Hardware | |
| Ports | 1 x WAN / LAN (10/100 BaseT) |
| Button | 1 x Reset 8s |
| LED's | Power, WAN / LAN, Wi-Fi, 3 x Signal strength |
| Power Supply | DC24V / 0.5A Power over Ethernet (Passive PoE) |
| Power Consumption | Max. 7W |
| Mains Adapter | Input: 100-240V AC. 50/60hz (Mains power adapter included) |
| Wireless | |
| Standard | IEEE 802.11a/b/g/n/ac |
| Frequency Bands | 2.4GHz and 5GHz |
| Transmit Power* | Max.30dBm |
| Sensitivity | 802.11b: -93dBm / 802.11g: - 74dBm / 802.11n: - 68dBm |
| Protocols and speeds** | 802.11ac: up to 433Mbps 802.11n: up to 150Mbps 802.11a: up to 54Mbps 802.11g: 54Mbps 802.11b: 11Mbps |
| Wireless Security | WPA-PSK / WPA2-PSK encryption |
| Antennas | 2 x 7Dbi Detachable Omni Directional (RSMA Connectors) |
| Range*** | Outdoor 500m / Indoor 150m (Typical) |
| Firmware | |
| WAN Type | PPPoE / Dynamic IP / Static IP / WISP / Repeater |
| DHCP Settings | Server / Client |
| Function | Time Setting / DDNS / Static Router / DHCP Server / Wireless Setting |
| Operating Modes | Access Point (AP), Client, Client Router, Repeater, Bridge |
| Dimensions | |
| Main Body | 180mm x 50mm x 50mm |
| Antennas | 250mm x 18mm |
| Environmental | |
| Operating Temperature | -30°C to +70°C |
| Storage Temperature | -40°C to +70°C |
| Relative Humidity (Operational) | 10% - 90% non-condensing |
| Relative Humidity (Storage) | 10% - 90% non-condensing |
| Ingress Protection | IP65 |
Notes:
* Subject to local legal restrictions
** Maximum Ethernet throughput is 100Mbps
*** Range will be dependent on the transmit power, receive sensitivity of the remote device and general surroundings.
