Mini Door-Entry Monitor (SB2)

Call us for a price

*Lead time of 2-3 days*


Wall-mounted colour monitor with 4.3" 16:9 screen and handset. Allows brightness and contrast control, plus adjustment of the volume of the ringtone, which can be customised with a choice of different melodies. Equipped as standard with 4 soft touch buttons for door-opening, self activation, switchboard call, silent mode and with door status indicator LEDs. Manages floor door calls as standard. Option of adding 4 additional buttons with accessory art. 6733W. Complete with 2 x 8-position DIP-switches for user code programming and button programming


Technical Specifications
General Data
Height (mm) 160
Width (mm) 175
Depth (mm) 22
Product Colour White RAL 9003
Product Weight (g) 600
Type of Finishing Materials ABS
Wall-Mounted Yes
Audio System Yes, with a dedicated accessory
Compatible Systems
Simplebus 2 Yes
Electrical Characteristics
Supply Voltage 22~35VDC
Display Size (inches) 4.3
Aspect Ratio 16:9
Resolution (pixels) 480 x 272
Audio Features
Microphone 6mm (Ø), Omnidirectional
Loudspeaker 40 (ø) x 5.1 (H)mm, 100 ohm, 0.25W
Hardware Features
Type of Buttons Capacitive
Service Buttons Lock-release, Silent, Door Open
Number of Push-Buttons 5
Removable Terminals Yes
Environmental and Compliance Features
IP Protection Rating IP30
Operation Temperature -5°C ~ +40°C
Operating Humidity (RH Max) 25 ~ 75%
Environmental class I (B1)
CE certifications RoHS II - 2011/65/UE (EN IEC 63000:2018), EMC 2014/30/UE (EN 61000-6-1:2007 , EN 61000-6-3:2007+A1:2011)
General Features
Door Opener Yes
Silent Mode (Privacy) Yes
Ringtone Volume Control Yes
Electronic Bell Yes
