16 Camera IP NVR (16 POE, Up To 8MP)

Home/IP Recorders/16 Camera IP NVR (16 POE, Up To 8MP)

1 of 4

Compatible with Windows, Mac, Android and iOS devices

£280.00

(£336.00 inc VAT)

Hard Drive:

NVR without Hard Drive has "Limited Warranty"

Quantity:

+ −

Order Code: NVR216S2

Description
Specification

This NVR (Network Video Recorder) has HD recording and playback of all channels. It includes a user friendly mouse driven interface with full remote network and mobile phone access. The NVR can auto detect ONVIF compatible IP cameras; it can support up to 8MP IP cameras and includes 16 POE ports to power POE cameras locally.

- 16 Channel Video & Audio
- Plug & Play 16 Port POE
- Supports up to 4K/8MP IP Cameras
- Bandwidth IN: 160Mbps, OUT: 64Mbps
- HDMI & VGA Output
- VCA with Compatible Cameras (see Special Features)
- ONVIF Compliance (Profiles S, G, C, Q, A, T)
- Supports H.264 and H.265
- Alarm 4 In, 1 Out, Two-way Audio
- Mac Compatible

Video/Audio Input

Video Input:

16ch H.264/H.265/Ultra265

Incoming Bandwidth:

160Mbps

Outgoing Bandwidth:

64Mbps

Supported Technologies:

Video/Audio Output

Live View/ Playback/ Recording Resolution:

8MP/6MP/5MP/4MP/3MP/1080P/720P/D1/VGA/CIF/QCIF

Frame Rate:

8MP, 6MP, 5MP, 4MP, 3MP, 1080P@30fps

Playback Capacity:

16ch D1/8ch 720P/4ch 1080P/3ch 3MP/2ch 4MP/1ch 8MP

HDMI Output:

3840x2160, 1920x1080, 1280x720, 1024x768

VGA Output:

1920x1080, 1280x720, 1024x768

Audio Output:

1ch, Line out

Hard Disk

Drive quantity:

Up to 2 SATA drives

Drive capacity:

Up to 10TB each

Network

Network Interface:

1 RJ45 10M/100M/1000M

Protocol:

RTP/RTCP, TCP/UDP ,HTTP, DHCP, DNS, NTP, P2P, UPnP, PPPoE

POE Interface:

16Ch 100Mbps, IEEE802.3af/IEEE802.3at

POE Max Power:

30W for single port/240W for all ports

General

Power Supply:

AC220V

Power Consumption:

Max 10W (without HDD, USB)

Operating Temperature:

-10°C ~ 55°C

Operating Humidity:

0% - 90% RH

Product Dimensions:

380mm(W) x 315mm(D) x 53mm(H)

Application

Supported OS:

Windows 7+, MacOS X 10.11+

Remote Software:

Internet Explorer 9+, EZStation VMS

Supported Devices:

iOS, Android

Notifications:

Email or Push

Interface

Video Outputs:

HDMI (x1), VGA (x1)

USB:

USB 3.0 (x1), USB 2.0 (x1)

Audio I/O:

Microphone in (x1), Audio line out (x1)

Alarm I/O:

Alarm input (x4), Alarm output (x1)

PTZ Control:

Onvif

Control:

Mouse control
