Hybrid DVR (12ch: 8HD+4IP)
This DVR has HD recording and playback of all channels. It includes a user-friendly mouse driven interface with full remote network and mobile phone access. The NVR can auto-detect ONVIF compatible IP cameras; it also supports AHD, TVI, CVI, and Analogue cameras.
- 12 Channel Video & Audio (up to 8 BNC and up to 4 IP cameras)
- Hybrid DVR (5-in-1)
- Supports up to 5MP Cameras
- Bandwidth IN: 56Mbps, OUT: 64Mbps
- HDMI, VGA & CVBS Output
- VCA with Compatible Cameras (see Special Features)
- ONVIF Compliance (Profiles S, G, C, Q, A, T)
- Supports H.264, or H.265
- Two-way Audio
- Mac Compatible
Video/Audio Input
Video Input:
12ch H.264/H.265
Incoming Bandwidth:
56Mbps
Outgoing Bandwidth:
60Mbps
Supported Technologies:
AHD, TVI, CVI, Analogue, IP
Hard Disk
Drive quantity:
Up to 1 SATA drive
Drive capacity:
Up to 8TB each
Storage and Backup
Recording Mode:
Manual, Continuous, Schedule, Motion, Pre/Post
Playback:
Search by Time, Calendar, Events
Backup Devices:
Via USB Memory Stick, HDD or over the network
Live View:
1, 4, 9 or 16 screens, Digital Zoom
General
Power Supply:
12V DC
Power Consumption:
Max 8W (without HDD, USB)
Operating Temperature:
-10°C ~ 55°C
Operating Humidity:
0% - 90% RH
Product Dimensions:
260mm(W) x 240mm(D) x 46mm(H)
Application
Supported OS:
Windows 7+, MacOS X 10.11+
Remote Software:
Internet Explorer 9+, EZStation VMS
Supported Devices:
iOS, Android
Mobile App:
EZView
Notifications:
Email or Push
Interface
Video Outputs:
HDMI (x1), VGA (x1), BNC (x1)
USB:
USB 2.0 (x2)
Audio I/O:
Microphone in (x1), Audio line out (x1)
Alarm I/O:
N/A
PTZ Control:
Onvif / RS-485
Control:
Mouse control
